About HID Xenon

High Intensity Discharge (HID) is a new type of lighting technology that's primarily different from the conventional halogen bulbs that use a heated tungsten filament. Unlike Halogen lamps, High-Intensity-Discharge (HID) lamps don't have a filament but create light by the arc between two electrodes. The arc activates the Xenon, which in turn ignites the metal halide. The light produced by an HID Xenon lighting system is greater than a standard halogen bulb and with less power consumption. On the road, HID Xenon lighting systems appear as a bright white beam which resembles natural daylight. The bright white beam offers greater visibility and road safety. In an HID Xenon lighting system, the voltage between the two electrodes rises firstly from 12V to 23000V and keeps stable at 8000V by using the Xenon HID ballasts system. Due to the ultra high voltage, the Xenon gas ionises and a super-bright beam is produced, whose color temperature is up to 12000K. The HID Xenon lighting is much more economic, more stable and brighter than the conventional automobile lighting.

Advantages of Xenon Light

LOW POWER CONSUMPTION The xenon bulb provides more than twice the amount of light of a halogen bulb, while only consuming half the power (wattage). Therefore, the driver can see more clearly, and the car has more power for other functions. Moreover, it is environmentally friendly, as less power means less fuel consumption. 3 TIMES BRIGHTERThe clear white light produced by the Xenon bulb is similar to daylight. Research has shown that this enables drivers to concentrate better. Furthermore, this particular light color reflects the road markings and signs better than conventional lighting. EXTREMELY LONG LIFEThe xenon bulb also delivers a marked contribution to road safety in the event of limited visibility due to weather conditions. In practical terms, the life span of the bulb is equal to that of the car, which means that the bulb need only be replaced in exceptional cases.

Temperature:

Color Temperature is a measurement in Degrees Kelvin that indicates the hue of a specific type of light source. Many people believe the misconception that color temperature is a rating of the brightness of the bulb or HID kit. This belief is completely false. The reality of the matter is that the higher the color temperature, the less useable light output you will obtain. Higher K kits such as 7000k, 7500k, etc. have been manufactured for individuals that are more concerned about the actual color output of their lights as opposed to the actual useable light output they produce.

Characteristic ：
Safety:

It will not burst because of bleb or hydrosphere.When the accident happens,the rheoscope in the ballast will make the power off so as to keep us safe.And we adopt high insulated wire and design without electromagnetism,make you working without any anxiety.


Long life:

The life-span is as long as 3000 hours,much more than the total hours that the automobile work at night.


Save electricity:

Only need the electricity of 35W,lightens the power load system greatly,it saves 40% on the electricity,improve vehicle performance correspondingly,save the energy.


Exceed the luminance:

The xenon bulb provides as three times light as halogen bulb. Therefore,the driver can see more higher,wider,farther.So it is safer to drive a vehicle.


Good colour temperature:

The CT is 4300K-12000K,is close to the sunlight and comfortable to our eyes,also benefit for the safe driving indirectly.


Easy to install:

Only need to insert the xenon lamp into the hole of the original light,fixed the ballast, connect and have the cable;And does not need to change the original part of vehicle.


HID standard ：
Work voltage:

It can work in a wide range of voltage.Such as in the voltage between 8V and 18V direct current,ballast can work.


Protect function:

1．Overloaded Protect
In order to prevent burning the bulb and letting the car owner find the vehicle trouble in time when the voltage is too high, when the power direct current presses and exceeds 18V,the stable device quits work automatically,make output power not exceed 45W,protect the stable device, prevent HID bulb from being damaged.
2．Low voltage Protect
In order to prevent the bulb from using up the automobile battery and then the automobile being unable to start normally.When the direct current is under 8V,the ballast will be out of work automatically so as to avoid damaging.
3．Unload Protected
When the ballast has not been connected with the bulb,in unloaded state,the ballast will be out of work automatically so as to prevent the high-tension electricity from injuring staff members.
4．Short Circuit Protect
Short circuit protect when the ballast meets the unexpected situation,in the state of shorting out,the stable device quits work automatically,avoid damaging.　　
5．The transposition protecting
When the stable device is in installation,operate people fault is it import power straight negative pole to when connecting inside out to make,the stable device quits work automatically,guarantee the stable device is not damaged.
6．Waterproof,dustproof,quakeproof performance


Start the performance power:

Power input when the standard voltage 12.8V fast, the electric current is not smaller than surveying and inviting 8.5A,make the xenon lamps connected in starting one second,he luminous flux reaches 20% of the standard luminance,in 4 seconds,he luminous flux reaches 80% of the standard luminance
